Description
Specifications:
- Amperage ratings: 15 A + 20 A + 20 A + 15 A (outer to centre)
- Poles: 4 (quad module: two single‑pole 15 A outer, one double‑pole 20 A centre)
- Voltage rating: 120/240 V AC
- Interrupting rating: 10 kA (10,000 A)
- Connection type: Plug‑in mount (Type DNPL / BR series compatible)
- Compatible load‑centres: Eaton/Cutler‑Hammer BR series and others including Challenger/Westinghouse/Novaline etc.
- Conductors: Suitable for typical residential #14‑#4 AWG copper/aluminium (depending on installation)
- Certifications: UL Listed and CSA Certified
