DNPL154015 - Eaton - 15/40/40/15 Amp Quad Circuit Breaker

Specifications:

• Amperage ratings: 15 A + 40 A + 40 A + 15 A (two outer single‑pole at 15 A each, one centre two‑pole at 40 A)
• Poles: 4 (quad module: two 1‑pole + one 2‑pole)
• Voltage rating: 120/240 V AC
• Interrupting rating: 10 kA at rated voltage
• Connection type: Plug‑in mount
• Module width: 2 inches (space‑saving quad design)
• Compatible load‑centres: Eaton / Cutler‑Hammer BR series and others (Challenger, Westinghouse, Novaline)
• Certifications: CSA approved, UL listed
