Description
Specifications:
- Amperage rating: 125 A
- Poles: 2 (double‑pole)
- Voltage rating: 120/240 V AC
- Interrupting rating: 10 kA @ rated voltage
- Mounting type: Plug‑on (1‑inch width style for BR load centers)
- Wire size: #4 AWG to 2/0 AWG copper/aluminum
- Trip type: Thermal‑magnetic, common‑trip mechanism
- Physical dimensions: Approx. 3 in height × 2 in width × 3 in depth
- Certification: UL 489 listed, CSA approved
- Compatible with: Eaton Type BR load centres
