Description
Specification
Model: NX-HEX96190-534W-5K | NX-HEX96190-534W-CCT | NX-HEX96190-534W-RGB
Type: Hexagon LED Ceiling Light (linear hex modules)
Wattage: 534 W total (comprising fourteen hex modules: 46" = 16 W, 18" = 6 W each)
Voltage: 100–277 V AC
Luminous Efficacy: 100–110 lm/W
Color Options:
- 5K: Fixed 5000 K
- CCT: Switchable 3000 K / 3500 K / 4000 K / 5000 K / 6500 K
- RGB: Full RGB control (exact color capabilities vary)
- CRI: > 80
- Beam Angle: 120°
- Lifetime: 50,000 hrs
- IP Rating: IP44 (splash/dust resistant)
- Operating Temp: –20 °C to +45 °C
- Housing: White; light source SMD2835
- Warranty: 3 years
- Application: Ideal for high-ceiling or commercial spaces—garages, workshops, gyms, offices, studios, warehouses
