Siemens SEQ24100SM 100A 1PH 24/48-Circuit Service Entrance Load Center, 3-Wire, 240 VAC

Specifications

• Model: SEQ24100SM
• Configuration: Single‑phase
• Voltage rating: 240 V
• Main breaker: 100 A included
• Number of circuits: 24 circuits (expandable to 48 with tandem breakers) Number of spaces: 48 spaces
• Interrupt rating: 65 kA
• Accepts conductor size: 4 AWG to 2/0 AWG
• Enclosure: Steel housing, indoor use, NEMA Type 1 (grey finish
• Mounting: Surface (flush or surface) — side‑mounted main breaker feed (“SM” suffix)
• Dimensions (approx): 13 ⅛ in (W) × 3 ¾ in (D) × 24 1⁄8 in (H)
