Description
Model Number: JL-103EE
Rated Loading: 2000W Tungsten / 2000VA Ballast
Rated Voltage: 347V AC
Power Consumption: 1.5VA
Rated Frequency: 50Hz / 60Hz
Operating Temperature: –40°C ~ +70°C
Time Delay: 20–120 seconds (prevents false switching from momentary light changes)
Leads Length: AWG #16, AWM1332, minimum 4"
Mounting Type: Twist-Lock (ANSI C136.10 standard)
Housing Material: UV-resistant polycarbonate, weatherproof design
Application: Street lighting / Flood lights / Outdoor area lighting (347V systems)
Warranty: 5 years
